Parameter

Power output:

100mW

Distance:

1000m@1200bps; 600m@9600bps

Baud rate:

1200/2400/4800/9600/19200bps

Channel Space:

1MHz(default)  12.5/25KHz（customize）

Bandwidth:

<25KHz

Receiving Sensibility:

-120dbm(1200bps);-115dbm(9600bps)

Compatible with

LS-U10, U100, U1000, U2000, U5000, LS-RDIO series, LS-RAIO series

Power

Power Supply:

5V DC （default)，3.3-3.6V(customize)

Transmitting current:

<40mA

Receiving current:

<20mA

Sleep current:

<20uA

General

Modulation:

FSK/GFSK

Frequency:

433MHz, or 400MHz, 450MHz, 470MHz or other

Data format：

8N1, 8EI, 8O1 programmable, or other customize

Channel No.：

8(default)，16/32/64(customize)

Interface:

TTL/ RS232/RS485

TX RX swift time

<10ms

Physical Properties

Dimension:

47mm×26mm×10mm
(exclude antenna connector and pin terminal)

Weight:

20g

Antenna connector:

50Ω,  SMA

Working temperature:

Industrial：-40℃~+85℃(TCXO)
